Fig. 71: Removing Bolt And Position Door Glass Top Run
Courtesy of FORD MOTOR CO.

7. Disconnect the door lock actuator electrical connector.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



Fig. 72: Disconnecting Door Lock Actuator Electrical Connector
Courtesy of FORD MOTOR CO.

8. Remove the door lock actuator rivet.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



Fig. 73: Removing Door Lock Actuator Rivet
Courtesy of FORD MOTOR CO.

9. Disconnect the actuating rods.

1. If equipped, disconnect the actuating rod from the lock cylinder.

2. Open the locking clip.

3. Disconnect the exterior door handle actuating rod from the front door latch.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



Fig. 74: Disconnecting Actuating Rod From Lock Cylinder
Courtesy of FORD MOTOR CO.

10. Position the front door latch aside.

z

Remove and discard the screws.

z

Position the latch aside.
