Fig. 60: Aligning Camshaft Synchronizer (4.2L)
Courtesy of FORD MOTOR CO.

CLUTCH PEDAL POSITION SWITCH



2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Removal & Installation - Blackwood, Expedition, F150 Pickup & Navigator - Gasoline



Removal & Installation

Disconnect the clutch pedal position switch electrical connector. Release the CPP switch from the orientation
clip. See Fig. 61 . Push the plastic retainer lock tabs together (1). See Fig. 62 . Slide the plastic retainer off the
CPP switch (2). Remove the CPP switch. See Fig. 63 . To install, reverse the removal procedure.

Fig. 61: Releasing Orientation Clip
Courtesy of FORD MOTOR CO.

NOTE:

Numbers in parenthesis refer to numbers in illustration.



2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Removal & Installation - Blackwood, Expedition, F150 Pickup & Navigator - Gasoline



Fig. 62: Removing Plastic Retainer
Courtesy of FORD MOTOR CO.

Fig. 63: Removing CPP Switch
Courtesy of FORD MOTOR CO.

CRANKSHAFT POSITION SENSOR



2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Removal & Installation - Blackwood, Expedition, F150 Pickup & Navigator - Gasoline



Removal & Installation

Disconnect negative battery cable. Raise and support vehicle. On V8 and V10 models, remove A/C compressor
to gain access. On all models, disconnect Crankshaft Position (CKP) sensor wire connector from engine
harness. See

Fig. 64

 or Fig. 65 . Remove CKP sensor mounting screws. Remove CKP sensor. To install, reverse

removal procedure. Tighten fasteners to specification. See TORQUE SPECIFICATIONS .

Fig. 64: Removing CKP Sensor (4.2L)
Courtesy of FORD MOTOR CO.

NOTE:

Engine design precisely locates Crankshaft Position (CKP) sensor. No CKP
sensor adjustment is necessary.

WARNING:

On Blackwood and Navigator models, the air suspension system must be
shut off prior to hoisting or jacking vehicle. Turn off the air suspension
switch, located below the glove box in the lower right side of the
passenger foot well.
