Fig. 57: Removing Fuel Filler Valve
Courtesy of FORD MOTOR CO.

Installation

NOTE:

Replace the fuel line O-ring seal.

NOTE:

Lubricate the fuel line O-ring seal with 5W30 engine oil meeting Ford
specification WSS-M2C153-G or equivalent prior to installation, to help
seal and ease the installation.

NOTE:

When tightening the fuel lines, a torque wrench adapter must be used with
the torque wrench. The use of a torque wrench adapter will alter the
effective torque of the torque wrench being used. To correct the effective
torque, a torque multiplication conversion must be used; Refer to
TORQUE MULTIPLICATION CONVERSION .



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines-Natural Gas - F150 Pickup



Fig. 58: Installing Fuel Filler Valve
Courtesy of FORD MOTOR CO.



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines-Natural Gas - F150 Pickup



Fig. 59: Installing Fuel Filler Valve Retaining Bolts
Courtesy of FORD MOTOR CO.

1. Follow the removal procedure in reverse order.

FILTER - FUEL FILLER VALVE

Special Tool(s)



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines-Natural Gas - F150 Pickup



Fig. 60: Identifying Special Tools
Courtesy of FORD MOTOR CO.

Removal

1. Remove the fuel filler valve; refer to FILLER VALVE - FUEL .

2. Position the fuel filler valve in a vise.

3. Remove the fitting from the fuel filler valve.
