Fig. 37: Removing Hose Clamp On Fuel Tank Filler Pipe Support/Caption>
Courtesy of FORD MOTOR CO.

4. Disconnect the fuel tank filler pipe hose from the fuel tank.



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines - F150 Pickup



Fig. 38: Disconnecting Fuel Tank Filler Pipe Hose From Fuel Tank
Courtesy of FORD MOTOR CO.

5. Remove the fuel filler vent hose from fuel tank.



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines - F150 Pickup



Fig. 39: Removing Fuel Filler Vent Hose From Fuel Tank
Courtesy of FORD MOTOR CO.

6. Remove the fuel tank filler pipe.

Installation

1. Follow the removal procedure in reverse order.



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines - F150 Pickup



Fig. 40: Installing Fuel Tank Filler Cap And Screws
Courtesy of FORD MOTOR CO.

FILTER

Special Tool(s)
