Ford F150 Pickup. Instruction - part 108

Fig. 83: Removing Upper Steering Column Cover
Courtesy of FORD MOTOR CO.

2. Position the electrical connector aside.

z

Release the push clip from the lower instrument panel steering column cover.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 84: Positioning Electrical Connector Aside
Courtesy of FORD MOTOR CO.

3. Pull the handle and remove the fuse door.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 85: Removing Fuse Door
Courtesy of FORD MOTOR CO.

4. Disconnect the hood latch release handle from the lower instrument panel steering column cover.

1. Remove the screws.

2. Disconnect the hood latch release handle from the steering column cover.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 86: Disconnecting Hood Latch Release Handle
Courtesy of FORD MOTOR CO.

5. Disconnect the parking brake release handle from the lower instrument panel steering column cover.

1. Remove the screws.

2. Disconnect the parking brake release handle.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup
