Fig. 79: Clipping Bulkhead Electrical Connectors Into Dash Panel
Courtesy of FORD MOTOR CO.

42. Install the bulkhead electrical connector insulator.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 80: Installing Bulkhead Electrical Connector Insulator
Courtesy of FORD MOTOR CO.

43. Connect the bulkhead wiring harness connectors.

1. Connect the bulkhead wiring harness connectors.

2. Tighten the bolts.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 81: Connecting Bulkhead Wiring Harness Connectors
Courtesy of FORD MOTOR CO.

44. Install the BJB into the mounting tabs.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 82: Installing BJB Into Mounting Tabs
Courtesy of FORD MOTOR CO.

45. Install the passenger air bag module. Refer to PASSENGER-SIDE AIR BAG MODULE .

46. Install the driver air bag module. Refer to DRIVER-SIDE AIR BAG MODULE .

INSTRUMENT PANEL - STEERING COLUMN COVER

Removal and Installation

1. Remove the upper steering column cover.

z

If equipped, disconnect the bi-fuel tank selector switch.

NOTE:

On automatic transmissions, move the shift lever to the 1 position to make
removal easier.
