Ford F150 Pickup. Instruction - part 25

Fig. 7: Disconnecting Radio Antenna Lead-In Cable And Radio Electrical Connectors
Courtesy of FORD MOTOR CO.

5. To install, reverse the removal procedure.

COMPACT DISC (CD) CHANGER - REGULAR CAB

Removal and Installation

1. Disconnect the battery ground cable (14301).

2. Remove the CD changer cover and electrical connector cover.

3. If equipped, remove the rear storage compartment.

1. Remove the nuts.

2. Remove the rear storage compartment.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Audio - F150 Pickup



Fig. 8: Removing Rear Storage Compartment
Courtesy of FORD MOTOR CO.

4. Remove the nuts and the CD changer.

z

Disconnect the electrical connector.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Audio - F150 Pickup



Fig. 9: Removing Nuts And CD Changer
Courtesy of FORD MOTOR CO.

5. To install, reverse the removal procedure.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Audio - F150 Pickup



2003 ACCESSORIES AND BODY, CAB

Speakers - F150 Pickup

DESCRIPTION AND OPERATION

SPEAKERS

On regular cab vehicles:

z

The rear speakers (18808) are located behind the rear corner trim panel (278D12) below the front safety
belt retractor and tongue (611B08).

z

The front speakers are located behind the front door trim panel (23942).

On SuperCab vehicles:

z

The rear speakers are located behind the rear door trim panels (27406) in the rear doors.

z

The front speakers are located behind the front door trim panels.

REMOVAL AND INSTALLATION

SPEAKERS - DOOR MOUNTED

Removal and Installation

1. Remove the door trim panel. Refer to FRONT DOOR TRIM PANEL or TRIM PANEL -- REAR

DOOR .

2. Remove the speaker.

1. Remove the screws.

2. Disconnect the electrical connector.

3. Remove the speaker.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Speakers - F150 Pickup





2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Speakers - F150 Pickup
