Lincoln MKS (2016 year). Manual - part 21

At every oil change interval as indicated by the information display

*

Inspect the steering linkage, ball joints, suspension, tie-rod ends, driveshaft and U-joints.

Inspect the tires, tire wear and measure the tread depth.

Inspect the wheels and related components for abnormal noise, wear, looseness or drag.

*

 Do not exceed one year or 10000 miles (16000 kilometers) between service intervals.

**

 Reset the Intelligent Oil-Life Monitor after engine oil and filter changes.  See Engine Oil Check (page 245).

Other maintenance items

1

Replace cabin air filter.

Every 20000 miles (32000
km)

Replace engine air filter.

Every 30000 miles (48000
km)

Change engine coolant.

2

At 100000 miles (160000
km)

Replace spark plugs.

Every 100000 miles
(160000 km)

Inspect accessory drive belt(s).

3

327

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance

Other maintenance items

1

Change automatic transmission fluid.

Every 150000 miles
(240000 km)

Replace accessory drive belt(s).

4

1

 Perform these maintenance items within 3000 miles (4800 kilometers) of the last engine oil and filter change. Do not exceed the designated

distance for the interval.

2

 Initial replacement at six years or 100000 miles (160000 kilometers), then every three years or 50000 miles (80000 kilometers).

3

 After initial inspection, inspect every other oil change until replaced.

4

 If not replaced within the last 100000 miles (160000 kilometers).

SPECIAL OPERATING
CONDITIONS SCHEDULED
MAINTENANCE

If you operate your vehicle primarily in any
of the following conditions, you need to
perform extra maintenance, as indicated. If
you operate your vehicle occasionally under
any of these conditions, it is not necessary to
perform the extra maintenance. For specific
recommendations, see your dealership
service advisor or technician.

Perform the services shown in the following
tables when specified or within 3,000 mi
(4,800 km) of the message appearing in the
information display prompting you to change
your oil.

•

Example 1: The message comes on at
28,751 mi (46,270 km). Perform the
30,000 mi (48,000 km) automatic
transmission fluid replacement.

•

Example 2: The message has not come
on, but the odometer reads 30,000 mi
(48,000 km) (for example, the Intelligent
Oil-Life Monitor was reset at 25,000 mi
(40,000 km)). Perform the engine air
filter replacement.

328

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance

Towing a trailer or using a car-top carrier

Change engine oil and filter as indicated by information display and perform services listed in the Normal
Scheduled Maintenance chart.

As required

Inspect and lubricate U-joints.

Inspect frequently, service
as required

Change PTU and rear axle fluid (AWD only). See axle and PTU maintenance items under Exceptions.

Every 30,000 mi
(48,000 km)

Change automatic transmission fluid.

Replace spark plugs.

Every 60,000 mi
(96,000 km)

Extensive idling or low-speed driving for long distances, as in heavy commercial use (such as delivery, taxi, patrol car or livery)

Change engine oil and filter as indicated by information display and perform services listed in the Normal
Scheduled Maintenance chart.

As required

Replace cabin air filter.

Inspect frequently, service
as required

Replace engine air filter.

Change automatic transmission fluid.

Every 30,000 mi
(48,000 km)

Change PTU and rear axle fluid (AWD only). See axle and PTU maintenance items under Exceptions.

Replace spark plugs.

Every 60,000 mi
(96,000 km)

329

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance

Operating in dusty or sandy conditions (such as unpaved or dusty roads)

Replace cabin air filter.

Inspect frequently, service
as required

Replace engine air filter.

Inspect the wheels and related components for abnormal noise, wear, looseness or drag.

Every 5,000 mi (8,000 km)

Rotate tires, inspect tires for wear and measure tread depth.

Change engine oil and filter.

*

Every 5,000 mi (8,000 km)
or six months

Perform multi-point inspection.

Change automatic transmission fluid.

Every 30,000 mi
(48,000 km)

Change PTU and rear axle fluid (AWD only). See axle and PTU maintenance items under Exceptions.

*

Reset your Intelligent Oil-Life Monitor after engine oil and filter changes.

Exclusive use of E85 (flex fuel vehicles only)

If ran exclusively on E85, fill the fuel tank full with regular unleaded fuel.

Every oil change

Exceptions

There are several exceptions to the Normal
Schedule:

330

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance

Axle and PTU Maintenance

The Power Transfer Unit (PTU) and rear axle
(AWD only) in your vehicle does not require
any normal scheduled maintenance. The PTU
lube will be more likely to require a fluid
change if the vehicle has experienced
extended periods of extreme/severe duty
cycle driving. Changing or checking the PTU
lubricant is not necessary unless the unit has
been submerged in water or shows signs of
leakage. Contact your authorized dealer for
service.

California Fuel Filter Replacement

If you register your vehicle in California, the
California Air Resources Board has
determined that the failure to perform this
maintenance item does not nullify the
emission warranty or limit recall liability
before the completion of your vehicle's useful
life. Ford Motor Company, however, urges
you to have all recommended maintenance
services performed at the specified intervals
and to record all vehicle service.

Hot Climate Oil Change Intervals

Vehicles operating in the Middle East, North
Africa, Sub-Saharan Africa or locations with
similar climates using an American
Petroleum Institute (API) Certified for
Gasoline Engines (Certification mark) oil of
SM or SN quality, the normal oil change
interval is 3,000 mi (4,800 km).

If the available API SM or SN oils are not
available, then the oil change interval is
1,800 mi (2,900 km).

Engine Air Filter and Cabin Air Filter
Replacement

The life of the engine air filter and cabin air
filter is dependent on exposure to dusty and
dirty conditions. Vehicles operated in these
conditions require frequent inspection and
replacement of the engine air filter and cabin
air filter.

331

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance

SCHEDULED MAINTENANCE RECORD

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

332

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

333

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

334

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

335

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

336

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

337

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

338

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

339

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

340

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

341

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

342

MKS (CLE) Canada/United States of America, enUSA, First Printing

Scheduled Maintenance
