SKIS VERIFICATION
APPLICABILITY
1. Reconnect all previously disconnected components and connectors.
2. Obtain the vehicle’s unique Personal Identification Number (PIN) assigned to it’s original
SKIM. This number can be obtained from the vehicle’s invoice or Chrysler’s Customer Center
(1-800-992-1997).
3. NOTE: When entering the PIN, care should be taken because the SKIM will only
allow 3 consecutive attempts to enter the correct PIN. If 3 consecutive incorrect
PIN’s are entered the SKIM will Lock Out the DRB III for 1 hour.
4. To exit Lock Out mode, the ignition key must remain in the Run position continually for 1
hour. Turn off all accessories and connect a battery charger if necessary.
5. With the DRB III, select Theft Alarm, SKIM and Miscellaneous. Then select desired
procedure and follow the steps that will be displayed.
6. If the SKIM has been replaced, ensure all of the vehicle ignition keys are programmed to the
new SKIM.
7. NOTE: Prior to returning vehicle to the costumer, perform a module scan to be sure
that all DTC’s are erased. Erase any DTC’s that are found.
8. With the DRB III erase all DTC’s. Perform 5 ignition key cycles leaving the key on for at least
90 seconds per cycle.
9. With the DRB III, read the SKIM DTC’s.
Are there any SKIM DTC’s?
All
Yes
→ Repair is not complete, refer to appropriate symptom.
No
→ Repair is complete.
VTSS VERIFICATION TEST - 1A
APPLICABILITY
1. Ensure all doors and the decklid are closed.
2. Open the driver door.
3. Remove the ignition key (but keep in hand).
4. Lock the doors with RKE transmitter.
5. Close the driver door.
6. - If the VTSS indicator lamp flashes rapidly and after approximately 15 seconds changes to
a slower flash, the system is operational.
7. - If the indicator fails to flash as described, there is a problem with the system. Select the
Identifying VTSS symptom from the Symptom List to troubleshoot.
Does the VTSS indicator lamp flash as specified?
All
Yes
→ Repair is complete.
No
→ Repair is not complete, refer to appropriate symptom.
238
VERIFICATION TESTS
Verification Tests —
Continued
