CAUTION: Use care when installing the caliper onto (3) Install the disc brake caliper over the brake shoes on the brake caliper adapter. Make sure the (4) Align the caliper guide pin bolt holes with the guide pins. Install the caliper guide pin bolts and (5) Install the tire and wheel assembly. Tighten the wheel mounting nuts to a torque of 135 N·m (100 (6) Lower the vehicle. moving the vehicle to set the shoes to the brake DISC BRAKE CALIPERS - REMOVAL (1) Using a brake pedal holding tool as shown (Fig. 70), depress the brake pedal past its first one inch of (2) Raise the vehicle. (Refer to LUBRICATION & MAINTENANCE/HOISTING - STANDARD PROCE- (3) Remove the rear tire and wheel assembly (Refer to 22 - TIRES/WHEELS - REMOVAL). (4) Remove the banjo bolt connecting the brake hose to the brake caliper (Fig. 71). There are two Fig. 69 Guide Pins And Boots 1 - PINS Fig. 70 Brake Pedal Holding Tool 1 - CLUTCH PEDAL (IF EQUIPPED WITH MANUAL TRANSAXLE) Fig. 71 Brake Hose Mounting 1 - BRAKE HOSE 5 - 38 BRAKES - BASE PL/SRT-4 DISC BRAKE CALIPER GUIDE PINS - FRONT - SRT-4 (Continued) |
