REMOVAL
WARNING: On vehicles equipped with airbags, disable the airbag system before attempting any steering
wheel, steering column, or instrument panel component diagnosis or service. Disconnect and isolate the
negative battery (ground) cable, then wait two minutes for the airbag system capacitor to discharge before
performing further diagnosis or service. This is the only sure way to disable the airbag system. Failure to
take the proper precautions could result in accidental airbag deployment and possible personal injury or
death.
NOTE: The heated seat switches are integral to the accessory switch bezel and cannot be serviced sepa-
rately.
1. Disconnect and isolate the negative battery cable.
2. Remove the center bezel from the instrument panel
and place it on a work bench (Refer to 23 - BODY/
INSTRUMENT
PANEL/BEZEL-CENTER
-
REMOVAL).
3. Remove the screws that secure the accessory
switch bank (4) to the back of the center bezel and
remove the accessory switch bank.
INSTALLATION
NOTE: There are different instrument panel acces-
sory switch banks available based on the option
content of the vehicle. Ensure the accessory
switch bank being installed matches the vehicle
options.
1. Position the accessory switch bank (4) onto the
back of the instrument panel center bezel.
2. Install the screws that secure the accessory switch
bank to the center bezel. Tighten the screws to
1N·m (8 in. lbs.).
3. Install the center bezel onto the instrument panel
(Refer to 23 - BODY/INSTRUMENT PANEL/BE-
ZEL-CENTER - INSTALLATION).
4. Reconnect the negative battery cable.
5. Verify heated seat system operation.
