7. Crack open the bleeder valve (3). 8. Allow fluid to flow out of bleed port until no more air bubbles can be seen in the transparent bleeder 9. Once fluid is free of air bubbles; make 15 quick actuations between clutch pedal stop positions. 10. Close the bleeder valve and disconnect the ser- vice filling machine. 11. To remove remaining air, actuate pedal 10 times slowly between pedal stop positions. NOTE: Pedal load should be approximately 25 lbs. 12. Check clutch pedal to see if vehicle is properly bled. 13. If vehicle is not properly bled, repeat procedure. 14. Remove bleeder cap from reservoir and replace reservoir cap. 15. Disconnect transparent bleeder hose from bleeder valve and replace dust cap. SPECIFICATIONS CLUTCH/HYDRAULICS/PEDALS TORQUE DESCRIPTION N·m Ft. Lbs. In. Lbs. Brake/Clutch Pedal & Booster-to-Dash Nuts 34 - 300 Brake/Clutch Pedal Assembly-to-Instrument Panel 34 - 300 Pressure Plate-to-Flywheel Bolts 28 23 250 Clutch Pedal Pivot Shaft Nut 42 31 - Damper-to-Transaxle Nuts 24 - 215 Driveplate-to-Crankshaft Bolts 95 70 - Flywheel-to-Crankshaft Bolts Gas 95 70 - Flywheel-to-Crankshaft Bolts Diesel 45 33 - Master Cylinder Pushrod Adj. Screw (LHD Models) 6 - 55 Modular Clutch-to-Drive Plate Bolts 88 65 - Master Cylinder Mounting Nuts (LHD) 15 - 130 PM CLUTCH 6 - 7 |
