Dodge Nitro. Manual - part 845

Fig. 117: Identifying Shift Rails & Support Plate
Courtesy of CHRYSLER LLC

11. Install shift rail (1) support plate (2) bolts and tighten to 8 N.m (71 in. lbs.).



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 118: Identifying Front Housing & Rear Housing
Courtesy of CHRYSLER LLC

12. Apply MOPAR® Gasket Maker to front housing.

13. Install front housing (1) on rear housing (2) and tighten bolts to 28 N.m (21 ft. lbs.).



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 119: Identifying Output Shaft & Snap Ring
Courtesy of CHRYSLER LLC

14. Install output shaft (1) snap ring (2) 4x4 only.



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 120: Identifying Output Shaft, Seal & Rear Housing
Courtesy of CHRYSLER LLC

15. Install output shaft (1) seal (2) in rear housing with Installer 9638.



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro
