Fig. 121: Identifying Shift Tower Opening & Shift Two Shift Rails
Courtesy of CHRYSLER LLC

16. Through the shift tower opening (1) move two shift rails (2) forward to lock the transmission in two gear.



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 122: Identifying Countershaft Bolt & Front Housing
Courtesy of CHRYSLER LLC

17. Install countershaft bolt (1) into the front housing (2) and tighten to 100 N.m (74 ft. lbs.).



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 123: Identifying Countershaft Plug & Front Housing
Courtesy of CHRYSLER LLC

18. Install countershaft plug (1) in front housing (2) with Installer 7829-A and Handle C-4171.



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 124: Identifying Shift Tower & Bolts
Courtesy of CHRYSLER LLC

19. Move shift rails to neutral.

20. To prevent sealant from plugging the transmission vent, apply just a thin film of MOPAR® Gasket Maker

to the shift tower (1) mating surface.

21. Install shift tower (1) and tighten bolts (2) to 14 N.m (10 ft. lbs.).
