Fig. 73: Identifying Synchronizer Hub & Detents
Courtesy of CHRYSLER LLC

10. Install 1-2 synchronizer hub (1) detents, springs, and balls (2).

2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro

Fig. 74: Installing First Gear Blocker Ring Into Synchronizer Hub
Courtesy of CHRYSLER LLC

11. Install first gear blocker ring (1) into synchronizer hub (2).

2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro

Fig. 75: Installing First Gear Outer Friction Ring Into Synchronizer Hub
Courtesy of CHRYSLER LLC

12. Install first gear outer friction ring (1) into synchronizer hub (2).

2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro

Fig. 76: Installing First Gear Inner Friction Ring Into Synchronizer Hub
Courtesy of CHRYSLER LLC

13. Install first gear inner friction ring (1) into synchronizer hub (2).

2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro
