Fig. 53: Identifying Idler Gear & Shaft Support
Courtesy of CHRYSLER LLC

3. Remove reverse idler gear (1) shaft support (2).



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 54: Identifying Idler Gear & Thrust Washer
Courtesy of CHRYSLER LLC

4. Remove reverse idler gear (1) thrust washer (2).



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 55: Identifying Idler Gear & Bearing
Courtesy of CHRYSLER LLC

5. Remove reverse idler gear (1) and bearing (2).



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 56: Identifying Plastic Countershaft Roller Bearing Cage & Screw Driver
Courtesy of CHRYSLER LLC

6. Break plastic countershaft roller bearing cage (1) with a screw driver (2). Then remove cage and roller

bearing.
