Dodge Nitro. Manual - part 827





Fig. 45: Identifying Countershaft Bearing & Retainers
Courtesy of CHRYSLER LLC

2. Remove countershaft bearing (1) retainer (2) bolts and remove retainers.



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 46: Identifying Countershaft Bearing & Housing
Courtesy of CHRYSLER LLC

3. Remove countershaft bearing (1) from housing (2) with a hammer and driver.



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 47: Identifying Input Shaft & Bearing Retainers
Courtesy of CHRYSLER LLC

4. Remove input shaft (1) bearing retainer bolts and remove retainers (2, 3).

5. Remove input shaft and bearing from housing with a dead blow hammer.



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 48: Identifying Input Shaft Seal & Housing
Courtesy of CHRYSLER LLC

6. Remove input shaft seal (1) from housing (2) with a hammer and driver.

INPUT SHAFT



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro
