Fig. 17: Identifying Countershaft Bolt & Front Housing
Courtesy of CHRYSLER LLC

5. Remove countershaft bolt (1) from the front housing (2).



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 18: Identifying Output Shaft, Seal & Rear Housing
Courtesy of CHRYSLER LLC

6. Remove output shaft (1) seal (2) from rear housing (3) with a seal pick.



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 19: Identifying Output Shaft & Snap Ring
Courtesy of CHRYSLER LLC

7. Remove output shaft (1) snap ring (2) 4x4 only.



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 20: Identifying Front Housing & Rear Housing
Courtesy of CHRYSLER LLC

8. Stand transmission on the rear housing and remove the housing bolts.

9. Remove front housing (1) from the rear housing (2).
