WEATHERSTRIP - HOOD TO COWL

Fig. 604: Cowl Weather-Strip
Courtesy of CHRYSLER LLC

1. Raise and support the hood.

2. Remove the cowl weather-strip (1) by peeling the cowl seal from the cowl grille.

INSTALLATION

WEATHERSTRIP - HOOD TO COWL

Fig. 605: Cowl Weather-Strip
Courtesy of CHRYSLER LLC

1. Install the cowl weather-strip (1) to the cowl grille.

2. Remove the hood support rod and lower the hood.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



WEATHERSTRIP - LIFT GATE OPENING

REMOVAL

WEATHERSTRIP - LIFT GATE OPENING

Fig. 606: Lift Gate Opening Weatherstrip
Courtesy of CHRYSLER LLC

1. Open the lift gate.

2. Remove the weatherstrip seal from the lift gate opening.

INSTALLATION

WEATHERSTRIP - LIFT GATE OPENING

Fig. 607: Lift Gate Opening Weatherstrip
Courtesy of CHRYSLER LLC



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



1. Install the weatherstrip to the upper right and left hand corners of the lift gate opening.

2. Using hand pressure seat the seal into the upper corners then seat across the header.

3. Seat the seal down the D-pillar to the lower flange on both sides.

4. Seat the seal along the lower flange to the slice joint.

5. Trim the weatherstrip if necessary, and connect the ends together along the flange.

WEATHERSTRIP - RDB - INNER

REMOVAL

WEATHERSTRIP - RDB - INNER

Fig. 608: Removing/Installing Inner Belt Molding Outboard
Courtesy of CHRYSLER LLC

1. Remove the door trim panel, see REMOVAL.

2. Rotate the inner belt molding outboard while pulling up to disengage the retention tabs.

INSTALLATION

WEATHERSTRIP - RDB - INNER

NOTE:

Seat the lift gate weatherstrip fully into all corners without stretching. If in
extreme cold temperatures preheating the weatherstrip to 23.8°C (75°F) may be
required to fully seat the weatherstrip.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 609: Removing/Installing Inner Belt Molding Outboard
Courtesy of CHRYSLER LLC

1. Press the belt molding onto the trim panel flange starting at the rear and working forward.

2. Install the door trim panel, see INSTALLATION.

WEATHERSTRIP - RDB - OUTER

REMOVAL

WEATHERSTRIP - RDB - OUTER
