2. Push down on the center of the trough (1) to flatten it out and install the remaining trough guide (3) and

guide shoe (2) into the track.

Fig. 592: Separating/Installing Trough Pins From Glass Lift Mechanisms
Courtesy of CHRYSLER LLC

3. Install the trough guide pins into the glass lift mechanism (3) and seat fully.

4. Install the glass, see INSTALLATION.

WEATHERSTRIP/SEALS

WEATHERSTRIP - A-PILLAR

REMOVAL

WEATHERSTRIP - A-PILLAR



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 593: Push Pin, Windshield A-Pillar Molding & Clips
Courtesy of CHRYSLER LLC

1. Using a trim stick C-4755 or equivalent, remove the push pin (1).

2. Remove the windshield A-pillar molding (2) and clips (3) from the windshield A-pillar.

INSTALLATION

WEATHERSTRIP - A-PILLAR

Fig. 594: Push Pin, Windshield A-Pillar Molding & Clips
Courtesy of CHRYSLER LLC

1. Install the windshield A-pillar molding (2) and clips (3) to the windshield A-pillar.

2. Install the push pin (1).

WEATHERSTRIP - FDB - INNER



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



REMOVAL

WEATHERSTRIP - FDB - INNER

Fig. 595: Removing/Installing Inner Door Weatherstrip
Courtesy of CHRYSLER LLC

1. Remove the door trim panel, see REMOVAL.

2. Rotate the outer belt molding outboard while pulling up to disengage the retention tabs.

INSTALLATION

WEATHERSTRIP - FDB - INNER

Fig. 596: Removing/Installing Inner Door Weatherstrip
Courtesy of CHRYSLER LLC

1. Press the belt molding onto the trim panel flange starting at the rear and working forward.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



2. Install the door trim panel, see INSTALLATION.

WEATHERSTRIP - FDB - OUTER

REMOVAL

WEATHERSTRIP - FDB - OUTER

Fig. 597: Removing Outer Belt Molding
Courtesy of CHRYSLER LLC

1 - OUTER BELT MOLDING
