Fig. 522: Bracket, Trim Attachment Bracket, Bracket Nuts & Hinge
Courtesy of CHRYSLER LLC

9. Install the bracket (1), trim attachment bracket (2) and bracket nuts (3) to the hinge (4) and tighten to 47.5

N.m (35 ft. lbs.).

Fig. 523: Removing/Installing Screw And Trim Covering From Hinge
Courtesy of CHRYSLER LLC

10. Install the trim covering and screw to the floor bracket and tighten to 3 N.m (26.5 in. lbs.).

11. Install the plastic seat cover clips to the seat back frame.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 524: Seat Back Trim Panel & Seat Back Frame
Courtesy of CHRYSLER LLC

12. Install the seat back trim panel (1) to the seat back frame (2).

INSTALLATION

SEAT BACK - REAR

60/40 Seat Back - 40

Fig. 525: 40 Seat Left Floor Bracket
Courtesy of CHRYSLER LLC

1. Install the left floor bracket to the seat frame.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 526: 40 Seat Right Floor Bracket
Courtesy of CHRYSLER LLC

2. Install the bracket (4), trim attachment bracket (2) and bracket nuts (1) to the hinge (3) and tighten to 47.5

N.m (35 ft. lbs.).

Fig. 527: 40 Seat Recliner Handle
Courtesy of CHRYSLER LLC

3. Install the recliner handle (3), washer (1) and screw to the floor bracket in the position noted during

removal and tighten to 7 N.m (62 in. lbs.).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 528: 40 Seat Floor Bracket Trim
Courtesy of CHRYSLER LLC

4. Install the trim covering (3) and screw (2) to the floor bracket and tighten to 3 N.m (26.5 in. lbs.).

Fig. 529: Removing/Installing Recliner Rod Nut And Recliner Rod
Courtesy of CHRYSLER LLC

5. Install the spacer, recliner rod (2) and recliner rod nut (1) to the position noted during removal and tighten

to 7 N.m (62 in. lbs.).

6. Remove the 40 seat back frame from the 60 seat back frame.
