60/40 Seat Back - 40

Fig. 485: Removing/Installing 40/60 Seat
Courtesy of CHRYSLER LLC

1. Remove the 40 and 60 seat, see REMOVAL.

2. Remove the screw and trim covering.

Fig. 486: Removing/Installing Nuts Attaching 40 60 Seat Back Frames
Courtesy of CHRYSLER LLC

3. Remove the nuts (1) attaching the 40 and 60 seat back frames.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 487: Removing/Installing Recliner Rod Nut And Recliner Rod
Courtesy of CHRYSLER LLC

4. Remove the recliner rod nut (1) and recliner rod (2).

5. Remove the 40 seat back frame from the 60 seat back frame.

Fig. 488: 40 Seat Floor Bracket Trim
Courtesy of CHRYSLER LLC

6. Trace (1) an outline of the recliner handle. Remove screw (2) and the floor bracket trim (3) from the

hinge.

NOTE:

Mark the position of the recliner lever prior to removal. This will make sure
that the recliner lever is in the proper position after installation.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 489: 40 Seat Recliner Handle
Courtesy of CHRYSLER LLC

7. Remove the screw (2), washer (1) and recliner handle (3) from the floor bracket.

Fig. 490: 40 Seat Right Floor Bracket
Courtesy of CHRYSLER LLC

8. Remove the bracket nuts (1), trim attachment bracket (2) and bracket (4) from the hinge (3).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 491: 40 Seat Left Floor Bracket
Courtesy of CHRYSLER LLC

9. Remove the left floor bracket from the seat frame.

60/40 Seat Back - 60

Fig. 492: Removing/Installing 40/60 Seat
Courtesy of CHRYSLER LLC

1. Remove the 40 and 60 seat, see REMOVAL.

2. Remove the screw and trim covering.
