Fig. 372: Headliner Rear Connections
Courtesy of CHRYSLER LLC

22. Remove the Center High Mount Stop Lamp (CHMSL) and disconnect the lift gate washer hose (4), refer

to REMOVAL .

23. Disconnect the electrical connector for the lift gate harness (1).

24. Remove the clip (3) from the header roof (2).

Fig. 373: Headliner & Roof
Courtesy of CHRYSLER LLC

25. Fold the rear seat in the down position and remove the headliner (2) from the roof (1).

CAUTION: It is necessary to fold the corner and the side up between the C and D

pillar area of the headliner to remove from the vehicle. The corner
must be folded up and not down to avoid damaging the headliner.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



INSTALLATION

HEADLINER

Fig. 374: Headliner & Roof
Courtesy of CHRYSLER LLC

1. Install the headliner (2) to the roof (1).

Fig. 375: Headliner Rear Connections
Courtesy of CHRYSLER LLC

2. Connect the lift gate washer drain hose (4) to the Center High Mounted Stop Lamp (CHMSL) and install

to the lift gate, refer to INSTALLATION .

CAUTION: It is necessary to fold the corner and the side up between the C and D

pillar area of the headliner to remove from the vehicle. The corner must be
folded up and not down to avoid damaging the headliner.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



3. Connect the electrical connector for the lift gate harness (1).

4. Install the clip (3) to the header roof (2).

Fig. 376: Radio/Satellite Connections L/F
Courtesy of CHRYSLER LLC

5. Connect the radio and/or satellite electrical connectors along the left A-pillar.

Fig. 377: Satellite Radio Body Antenna Connector, Power Connector & Radio Body Antenna
Connector
Courtesy of CHRYSLER LLC

6. Connect the satellite radio body antenna connector (1).

7. Connect the power connector (2).

8. Connect the radio body antenna connector (3).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 378: DVD Electrical Connector
Courtesy of CHRYSLER LLC

9. Attach the harness clip (2) to the D-pillar body (1).

10. Connect the DVD electrical connectors (3).

Fig. 379: Lift Gate Washer Hose
Courtesy of CHRYSLER LLC

11. Connect the lift gate washer hoses (1) with a union at the A-pillar.

NOTE:

Install a union where the lift gate washer hose was cut during removal.
