Fig. 380: Dual Lock Areas, Sunroof, Spacer Foam Blocker, Headliner & Sunroof Motor Jumper
Courtesy of CHRYSLER LLC

12. Connect the sunroof motor jumper (5).

13. Remove the tape backing from the spacer foam blocker (3), use hand pressure on the foam blocker to

stick the headliner and the sunroof together.

14. Use hand pressure at the dual lock areas (1) of the headliner (4) to make sure the headliner sticks to the

sunroof (2).

Fig. 381: Mirror Electrical Connector
Courtesy of CHRYSLER LLC

15. Connect the electrical connector (1) for the mirror (2).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 382: Harness Clip, D-Pillar Body & Body Harness Connectors
Courtesy of CHRYSLER LLC

16. Connect the body harness connectors (3).

17. Attach the harness clip (1) to the D-pillar body (2).

18. Install the assist handles, see INSTALLATION.

19. Install the visors, see INSTALLATION.

20. Install the visor supports, see INSTALLATION.

21. Install the overhead console, refer to INSTALLATION .

22. Install the A-pillar trim and grab handles, see INSTALLATION.

23. Install the upper B-pillar trim, see INSTALLATION.

24. Install the quarter trim panels, see INSTALLATION.

25. Install the sunroof opening trim ring, if equipped.

26. Connect the negative battery cable.

LATCH - ARMREST LID

REMOVAL

LATCH - ARMREST LID



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 383: Armrest Lid Latch
Courtesy of CHRYSLER LLC

1. Remove the two screws (1) attaching the console lid latch (2) to the console lid (3).

2. Remove the lid latch (2) from the console lid (3).

INSTALLATION

LATCH - ARMREST LID

Fig. 384: Armrest Lid Latch
Courtesy of CHRYSLER LLC

NOTE:

Using a grease pencil or equivalent, mark location of lid latch (2) on the console
lid (3) for installation alignment.

NOTE:

Align the lid latch (2) with the reference marks made during removal.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



1. Install the two screws (1) attaching the console lid latch (2) to the console lid (3).

2. Check the adjustment of the lid latch (2) and adjust as necessary by loosening the two screws (1) and

moving the lid latch (2) right or left as needed until the console lid (3) closes properly.

LID - FLOOR CONSOLE

REMOVAL

LID - FLOOR CONSOLE

Fig. 385: Screws, Console Lid, Hinge & Console
Courtesy of CHRYSLER LLC

1. Remove the two screws (1) attaching the console lid (2) to the hinge (3).

2. Remove the console lid (2) from the hinge (3).

3. Remove the two screws (5) attaching the hinge (3) to the console (4).

4. Remove the hinge (3) from the console (4).

INSTALLATION

LID - FLOOR CONSOLE



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro
