Fig. 351: Lower B Pillar Cover
Courtesy of CHRYSLER LLC

1. Using a trim stick C-4755 or equivalent, pry up on the trim panel (2), releasing the retaining clips from

the body (4).

2. Remove the trim panel (2) from the B-pillar (1).

3. Remove the trim panel (2) by sliding the panel forward releasing the panel from the scuff clips in the

body (3).

INSTALLATION

COVER - B PILLAR LOWER

Fig. 352: Lower B Pillar Cover
Courtesy of CHRYSLER LLC

1. Align and install the trim panel clips (3) rearward and into quarter trim panel.

2. Push the trim panel (2) down into the body (4) using hand pressure until all clips are seated.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



3. Align and install the trim panel (2) to the body slots (1) on the B-pillar. Snap into place using hand

pressure.

COVER - B PILLAR UPPER

REMOVAL

COVER - B PILLAR UPPER

Fig. 353: Upper B-Pillar Trim
Courtesy of CHRYSLER LLC

1. Remove the seat belt bolt (3).

2. Using a trim stick C-4755 or equivalent, pry out the screw cover from the top of the trim panel (2),

remove the screw.

3. Remove the trim (2) by sliding up and out of the B-pillar lower trim.

4. Remove the seatbelt webbing from the B-pillar upper trim (2).

INSTALLATION

COVER - B PILLAR UPPER



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 354: Upper B-Pillar Trim
Courtesy of CHRYSLER LLC

1. Feed the seatbelt webbing through the B-pillar trim (2). Slide the belt adjuster to top position.

2. Install the trim (2) by sliding down and into the B-pillar lower trim.

3. Align the 4-way locator and seat the B-pillar trim (2) to the body.

4. Install the screw and screw cover.

5. Install the seat belt bolt (3) and tighten to 44.5 N.m (33 ft. lbs.).

COVER - C PILLAR

REMOVAL

COVER - C PILLAR

Fig. 355: C-Pillar Cover
Courtesy of CHRYSLER LLC



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



1. Remove the seat belt bolt (3).

2. Using a trim stick C-4755 or equivalent, pry out the screw cover from the top of the trim panel (2),

remove the screw.

3. Remove the trim (2) by sliding up and out of the quarter trim molding.

4. Remove the seatbelt webbing from the C-pillar trim (2).

INSTALLATION

COVER - C PILLAR

Fig. 356: C-Pillar Cover
Courtesy of CHRYSLER LLC

1. Feed the seatbelt webbing through the C-pillar trim (2).

2. Install the trim (2) by sliding down and into the quarter trim molding.

3. Align the 4-way locator and seat the C-pillar trim (2) to the body.

4. Install the screw and screw cover.

5. Install the seat belt bolt (3) and tighten to 62 N.m (46 ft. lbs.).

CAP - FLOOR CONSOLE END

REMOVAL

CAP - FLOOR CONSOLE END
