5. Install the rivet (4) connecting the splash shield to the side sill molding.

6. Install all remaining push pins.

7. Install the rivet (3) into the hole in the wheel house liner and lower front fascia.

Fig. 274: Removing/Installing Rivets Connecting Fender Flare To Wheel House Liner
Courtesy of CHRYSLER LLC

8. Install four rivets to the front fender flare molding, wheel house liner and the fender.

9. Install wheel and tire and torque the wheel nuts to 136 N.m (100 ft. lbs.).

SHIELD - REAR WHEELHOUSE SPLASH

REMOVAL

SHIELD - REAR WHEELHOUSE SPLASH

Fig. 275: Rear Wheelhouse Splash Shield



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Courtesy of CHRYSLER LLC

1. Remove the rear wheel flare molding, see REMOVAL.

2. Remove the two push pins securing the sill plate molding to the wheel liner and body.

3. Remove the four push pins (3) at the wheelhouse opening (1).

4. Remove the wheel liner (2) from the wheelhouse opening (1).

INSTALLATION

SHIELD - REAR WHEELHOUSE SPLASH

Fig. 276: Rear Wheelhouse Splash Shield
Courtesy of CHRYSLER LLC

1. Install the wheel house liner (2) to the wheel house opening (1).

2. Install the four push pins (3) to the wheel house liner (2).

3. Install the two push pins securing the sill plate molding and the wheel house liner to the body.

4. Install the rear wheel flare molding, see INSTALLATION.

HOOD

BUMPER - HOOD

REMOVAL

BUMPER - HOOD



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 277: Hood Adjustment Bumper
Courtesy of CHRYSLER LLC

1. Remove the hood adjustment bumpers.

INSTALLATION

BUMPER - HOOD

Fig. 278: Hood Adjustment Bumper
Courtesy of CHRYSLER LLC

1. Install the hood adjustment bumpers. Make sure there are no excessive gaps between the areas around the

hood, adjust as necessary, see SPECIFICATIONS.

HINGE - HOOD

REMOVAL



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



HINGE - HOOD

Fig. 279: Screws, Fender & Applique
Courtesy of CHRYSLER LLC

1. Raise and support the hood.

2. Remove the two screws (1) from the fender applique.

3. Use a trim stick C-4755 or equivalent, separate the fender applique (3) from the fender (2).

Fig. 280: Support Cylinder
Courtesy of CHRYSLER LLC

4. Remove hood support cylinder, see REMOVAL.

NOTE:

It is not necessary to remove the hood to replace one or both hinges. The
hinges can be replaced one at a time.
