Fig. 261: Identifying Name Plate (2 Of 2)
Courtesy of CHRYSLER LLC

1. Remove protective cover from adhesive tape on back of emblem.

2. Position the correct emblem properly on the body.

Fig. 262: Identifying Name Plate (1 Of 2)
Courtesy of CHRYSLER LLC

3. Position the correct emblem properly on the body.

4. Press emblem firmly to the body with the palm of hand.

5. If temperature is below 21°C (70°F) warm emblem with a heat lamp or gun to assure adhesion. Do not

exceed 52°C (120°F) when heating emblem.

NOTE:

Before applying the emblem, clean the body surface with MOPAR® Super Kleen
solvent or equivalent.

2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro

PANEL - A-PILLAR

REMOVAL

PANEL - A-PILLAR

Fig. 263: Push Pin, Windshield A-Pillar Molding & Clips
Courtesy of CHRYSLER LLC

1. Using a trim stick C-4755 or equivalent, remove the push pin (1).

2. Remove the windshield A-pillar molding (2) and clips (3) from the windshield A-pillar.

INSTALLATION

PANEL - A-PILLAR

Fig. 264: Push Pin, Windshield A-Pillar Molding & Clips
Courtesy of CHRYSLER LLC

2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro

1. Install the windshield A-pillar molding (2) and clips (3) to the windshield A-pillar.

2. Install the push pin (1).

RACK - LUGGAGE

REMOVAL

RACK - LUGGAGE

Fig. 265: Roof Rack Assembly
Courtesy of CHRYSLER LLC

1. Remove the five nuts (1) from the roof rack (2).

2. Remove the roof rack (2) from the roof (3).

INSTALLATION

RACK - LUGGAGE

1 - Nuts
2 - Roof Rack
3 - Roof

2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro

Fig. 266: Roof Rack Assembly
Courtesy of CHRYSLER LLC

1. Carefully install the roof rack (2) to the roof (3).

2. Install five nuts (1) and tighten the nuts to 6.2 N.m (55 in. lbs.).

RUNNING BOARD - FULL

REMOVAL

RUNNING BOARD - FULL

Fig. 267: Running Board
Courtesy of CHRYSLER LLC

1 - Nuts
2 - Roof Rack
3 - Roof
