1. Position the new mirror glass holder to the mirror assembly.

2. Align the mirror glass holder's attaching fingers to the mirror motor housing.

3. Using one hand, firmly press the mirror glass holder assembly into place while at the same time

supporting the housing assembly from the backside with the other hand.

4. Verify retention of the mirror glass holder assembly by gently pulling outward on the mirror glass holder.

GRILLE - RADIATOR

REMOVAL

GRILLE - RADIATOR

CAUTION: It is important to make sure the motor is square to the glass holder

(attaching fingers) prior to glass holder attachment, otherwise the glass
holder could be installed incorrectly causing poor retention and possible
repeat failure.

NOTE:

Position the mirror glass holder so that the moisture drain hole on the
mirror glass holder assembly is facing downward.

NOTE:

Ensure that the protective rubber cover of the mirror motor housing is
positioned correctly around the bottom of the fingers area.

NOTE:

Pressure must be applied equally over the center portion of the mirror to
engage the mirror glass holder's attaching fingers to the corresponding
fingers on the housing assembly. One or more clicks may be heard when
finger engagement takes place.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 235: Grille Torx Screws LT
Courtesy of CHRYSLER LLC

1. Remove the torx screws (1) from the grille to radiator support.

2. Remove the torx screw (2) from the grille to fender.

Fig. 236: Grille Torx Screws RT
Courtesy of CHRYSLER LLC

3. Raise and support the hood.

4. Remove the torx screws (1) from the grille to radiator support.

5. Remove the torx screw (2) from the grille to fender.

Fig. 237: Removing/Installing Grille Push Pins
Courtesy of CHRYSLER LLC

6. Remove the push pins (1) from the grille.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 238: Grille Side Fastener
Courtesy of CHRYSLER LLC

7. Carefully pull on the grille assembly to release the fasteners on both sides of the grille.

8. Remove the front lamp, side marker lamp and the turn signal lamp connectors.

Fig. 239: Grille Lower Fastener
Courtesy of CHRYSLER LLC

9. Carefully pull on the grille assembly to release the fasteners located on the lower part of the grille.

10. Remove the front lamp units from both sides of the grille, refer to REMOVAL .

INSTALLATION

GRILLE - RADIATOR



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 240: Grille Lower Fastener
Courtesy of CHRYSLER LLC

1. Install the front lamp units to both sides of the grille, refer to INSTALLATION .

2. Install the grille to the vehicle and connect the front lamp, side marker lamp and the turn signal lamp

connectors.

3. Carefully push the lower part of the grille until the lower grille fasteners lock properly into position.

Fig. 241: Grille Side Fastener
Courtesy of CHRYSLER LLC

4. Position properly then carefully push the sides of the grille until the fasteners lock properly into position.

NOTE:

This step requires proper positioning of the grille so as both side of the
grille are installed at the same time.
