Fig. 219: Removing/Installing Rear Door Glass
Courtesy of CHRYSLER LLC

2. Install the rear door glass to the window opening in the door, see INSTALLATION.

Fig. 220: Electrical Connector, Carrier Plate, Screws & Door
Courtesy of CHRYSLER LLC

3. Install the carrier plate to the door, see INSTALLATION.

4. Cycle the window several times to make sure the window doesn't bind on the outer weatherstrip or run

channel.

PANEL - DOOR TRIM REAR

REMOVAL

PANEL - DOOR TRIM REAR



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 221: Removing/Installing Rear Door Trim Panel
Courtesy of CHRYSLER LLC

1. Remove the door handle trim bezel (6).

2. Remove the fastener (5) from the handle area of the front door trim (4).

3. Use a very thin pry tool to remove the cap screw covers (3) from the door trim (4).

4. Remove the screws (2) from the front door trim (4).

5. Remove the power window switch and disconnect the electrical connector.

6. Disengage the trim panel from the four way locator at the handle area of the trim panel, then carefully

remove the door trim panel (4) from the door (1) by lifting upward until removed from the door lock and
the mounting attachments on the carrier plate.

INSTALLATION

PANEL - DOOR TRIM REAR

Fig. 222: Removing/Installing Rear Door Trim Panel



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Courtesy of CHRYSLER LLC

1. Carefully install the door trim panel (4) to the door (1) by lifting upward and over the door lock into the

trim panel then attach the trim panel to the carrier plate attachment points.

2. Connect the electrical connector and install the power window switch.

3. Install the screws (2) to the front door trim (4).

4. Install the cap screw covers (3) to the front door trim (4).

5. Install the fastener (5) at the handle area of the front door trim (4) and tighten screw to 5.5 N.m (50 in.

lbs.).

6. Install the door handle trim bezel (6).

REGULATOR - POWER WINDOW

REMOVAL

REGULATOR - POWER WINDOW

1. Replace the carrier plate, see REMOVAL.

INSTALLATION

REGULATOR - POWER WINDOW

1. Install the carrier plate, see INSTALLATION.

EXTERIOR

APPLIQUE - FRONT FENDER

REMOVAL

APPLIQUE - FRONT FENDER

NOTE:

The window regulator is part of the carrier plate and is not serviceable. Replace
the carrier plate if the regulator fails.

NOTE:

The window regulator is part of the carrier plate and is not serviceable. Replace
the carrier plate if the regulator fails.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 223: Screws, Fender & Applique
Courtesy of CHRYSLER LLC

1. Remove the two screws (1) from the fender applique (3).

2. Use a trim stick C-4755 or equivalent, separate the fender applique (3) from the fender (2).

INSTALLATION

APPLIQUE - FRONT FENDER

Fig. 224: Screws, Fender & Applique
Courtesy of CHRYSLER LLC

1. Align the fender applique (3) to the fender assembly (2) and apply enough hand pressure in order to make

sure the clips are fully seated.

2. Install the two screws (1) to the fender applique (3).
