Fig. 204: Removing/Installing Third Latch Attachment Point
Courtesy of CHRYSLER LLC

2. It is necessary to align the third attachment point prior to attaching the second point, but do not attach at

this time.

Fig. 205: Removing/Installing Second Latch Attachment Point
Courtesy of CHRYSLER LLC

3. Install the second latch attachment point to the latch bracket.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 206: Removing/Installing Third Latch Attachment Point
Courtesy of CHRYSLER LLC

4. Install the third latch attachment point to the latch bracket.

Fig. 207: Release Rod & Swing Clips
Courtesy of CHRYSLER LLC

5. Install the release rod (1) then engage the two swing clips (2).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 208: Identifying Carrier Plate Slots
Courtesy of CHRYSLER LLC

6. Install the latch bracket assembly to the carrier plate slots (1) then slide the latch bracket until fully

seated.

Fig. 209: Disconnecting/Connecting Latch Electrical Connector
Courtesy of CHRYSLER LLC

7. Connect the latch electrical connector.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 210: Electrical Connector, Carrier Plate, Screws & Door
Courtesy of CHRYSLER LLC

8. Install the carrier plate, see INSTALLATION.

Fig. 211: Adjusting Rear Door Latch
Courtesy of CHRYSLER LLC

9. Adjust the latch as needed, see ADJUSTMENTS.

ADJUSTMENTS

LATCH - REAR DOOR
