REMOVAL

LATCH - REAR DOOR

Fig. 196: Electrical Connector, Carrier Plate, Screws & Door
Courtesy of CHRYSLER LLC

1. Remove the carrier plate, see REMOVAL.

Fig. 197: Disconnecting/Connecting Latch Electrical Connector
Courtesy of CHRYSLER LLC

2. Disconnect the latch electrical connector.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 198: Carrier Plate Slots
Courtesy of CHRYSLER LLC

3. Turn the carrier plate over and slide the latch bracket assembly to remove from carrier.

Fig. 199: Release Rod & Swing Clips
Courtesy of CHRYSLER LLC

4. Remove the release rod (1) by disengaging the two swing clips (2).

NOTE:

All the lock rods are color coded to help identify the location for the
particular lock rod.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 200: Removing/Installing First Latch Attachment Point
Courtesy of CHRYSLER LLC

5. Remove the first latch attachment point from the latch bracket.

Fig. 201: Removing/Installing Second Latch Attachment Point
Courtesy of CHRYSLER LLC

6. Remove the second latch attachment point from the latch bracket.

NOTE:

The latch has three attachment points to the latch bracket.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 202: Removing/Installing Third Latch Attachment Point
Courtesy of CHRYSLER LLC

7. Remove the third latch attachment point from the latch bracket and remove the latch from the latch

bracket.

INSTALLATION

LATCH - REAR DOOR

Fig. 203: Removing/Installing First Latch Attachment Point
Courtesy of CHRYSLER LLC

1. Install the first latch attachment point to the latch bracket.

NOTE:

The latch has three attachment points to the latch bracket and need to be
attached in the following order:
