HANDLE - INTERIOR DOOR

Fig. 188: Carrier & Interior Handle
Courtesy of CHRYSLER LLC

1. Remove the door trim panel, see REMOVAL.

2. Remove the interior lock rod from the interior handle (2).

Fig. 189: Push Pin, Handle & Spring
Courtesy of CHRYSLER LLC

3. Remove the push pin (1) from the handle.

4. Remove the spring (3) and handle (2) from the carrier.

INSTALLATION

HANDLE - INTERIOR DOOR



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 190: Push Pin, Handle & Spring
Courtesy of CHRYSLER LLC

1. Install the handle (2) and spring (3) to the carrier.

2. Install the push pin (1) into the carrier, spring and the handle.

Fig. 191: Carrier & Interior Handle
Courtesy of CHRYSLER LLC

3. Install the interior lock rod to the interior handle (2). Make sure the lock rod is positioned properly to the

carrier (1).

4. Install the door trim panel, see INSTALLATION.

HINGE - REAR DOOR

NOTE:

Make sure that the push pin is seated flush with the carrier.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



REMOVAL

HINGE - REAR DOOR

Fig. 192: Removing/Installing Upper/Lower Hinges, Door & Nuts
Courtesy of CHRYSLER LLC

1. Remove the rear door, see REMOVAL.

Fig. 193: Upper/Lower Door Hinge & Bolts
Courtesy of CHRYSLER LLC

2. Remove the (2) that secure the upper door hinge (1) and lower door hinge (3) to the body of the B-pillar

and remove the hinges.

NOTE:

Use a grease pencil or equivalent, mark the location of the upper (1) and
lower (3) hinge on the body of the lower B-pillar for alignment during
installation.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



INSTALLATION

HINGE - REAR DOOR

Fig. 194: Upper/Lower Door Hinge & Bolts
Courtesy of CHRYSLER LLC

1. Install the upper (1) and lower (3) hinges onto B-pillar and loosely install the bolts (2).

2. Align the hinges to the B-pillar using the reference marks made during the removal procedure and tighten

the bolts to 26 N.m (19 ft. lbs.).

Fig. 195: Removing/Installing Upper/Lower Hinges, Door & Nuts
Courtesy of CHRYSLER LLC

3. Install the rear door, see INSTALLATION.

LATCH - REAR DOOR
