Fig. 172: Door Glass & Window Regulator
Courtesy of CHRYSLER LLC

3. Access the window regulator through the hole in the carrier plate. Disconnect the window regulator (2)

from the door glass (1).

Fig. 173: Rotating Glass Upward/Downward Inside Run Channel
Courtesy of CHRYSLER LLC

4. Rotate the glass upward inside the run channel.

NOTE:

Place the glass in the full down position in order to access the window
regulator.

NOTE:

The following two graphics are shown with the carrier removed for clarity.

2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro

Fig. 174: Removing/Installing Rear Door Glass
Courtesy of CHRYSLER LLC

5. Remove the door glass from the window opening in the door.

INSTALLATION

GLASS - REAR DOOR

Fig. 175: Removing/Installing Rear Door Glass
Courtesy of CHRYSLER LLC

1. Install the door glass to the window opening in the door.

NOTE:

The following two graphics are shown with the carrier removed for clarity.

2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro

Fig. 176: Rotating Glass Upward/Downward Inside Run Channel
Courtesy of CHRYSLER LLC

2. Rotate the glass downward into the run channel.

Fig. 177: Door Glass & Window Regulator
Courtesy of CHRYSLER LLC

3. Access the window regulator through the hole in the carrier plate. Connect the door glass (1) to the

window regulator (2).

2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro

Fig. 178: Removing/Installing Inner Belt Molding Outboard
Courtesy of CHRYSLER LLC

4. Press the belt molding onto the trim panel flange starting at the rear and working forward.

Fig. 179: Removing/Installing Rear Door Trim Panel
Courtesy of CHRYSLER LLC

5. Install the trim panel. See INSTALLATION.

6. Cycle the window several times to make sure the window doesn't bind on the outer weatherstrip or run

channel.

HANDLE - EXTERIOR DOOR

REMOVAL

HANDLE - EXTERIOR DOOR
