1. Carefully position the door (2) to the upper (1) and lower (3) hinges using a suitable lifting device.

2. Loosely install the nuts (4) to the door studs and hinges at the B-pillar.

3. Align the door to the body using the reference marks made during the removal procedure.

4. Tighten the hinge to door nuts to 36.5 N.m (27 ft. lbs.).

Fig. 167: Disconnecting/Connecting Door Harness Electrical Connector From/To Body Connector
Courtesy of CHRYSLER LLC

5. Connect the door harness electrical connector (1) to the body connector (2) at the B-pillar.

6. Connect the negative battery cable.

7. Adjust the door as necessary. See SPECIFICATIONS.

ADJUSTMENTS

DOOR - REAR

FORE/AFT

NOTE:

It is recommended that you adjust the rear door before adjusting the front door.

Door adjustment measurements should be taken from stationary or
welded body panels like the roof, rocker or quarter panels.

During adjustment procedures, it is recommended that all the hinge
fasteners be loosened except for the upper most fasteners. Adjustments
can be made using the upper fasteners to hold the door with final torque
of the fasteners occurring after correct door positioning is achieved.

NOTE:

Fore/aft (lateral) door adjustment is done by loosening the hinge to the hinge
pillar fasteners one hinge at a time and moving the door to the correct position.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



1. Support the door with a suitable lifting device.

2. Loosen the hinge to hinge pillar fasteners. See REMOVAL.

3. Adjust the door to the correct position. See SPECIFICATIONS.

4. Tighten the hinge pillar fasteners to 26 N.m (19 ft. lbs.). See INSTALLATION.

UP/DOWN

1. Support the door with a suitable lifting device.

2. Remove the latch striker. See REMOVAL.

3. Loosen the hinge to hinge pillar fasteners. See REMOVAL or loosen the hinge to door fasteners . See

REMOVAL.

4. Adjust the door to the correct position. See SPECIFICATIONS.

5. Tighten the hinge pillar fasteners to 26 N.m (19 ft. lbs.) or the door to hinges fasteners to 36.5 N.m (27 ft.

lbs.). See INSTALLATION.

6. Install the latch striker. See INSTALLATION.

IN/OUT

1. Support the door with a suitable lifting device.

2. Remove the latch striker. See REMOVAL.

3. Loosen the hinge to door fasteners. See REMOVAL.

4. Adjust the front of the door to the correct position. See SPECIFICATIONS.

5. Tighten the door to hinges fasteners to 36.5 N.m (27 ft. lbs.).

6. Install the latch striker. See INSTALLATION.

APPLIQUE - REAR DOOR

REMOVAL

APPLIQUE - REAR DOOR

NOTE:

Use a suitable body sealer on the hinge to body mating surfaces.

NOTE:

Up/down door adjustment is done by loosening either the hinge to the hinge
pillar fasteners or the hinge to door fasteners and moving the door to the
correct position.

NOTE:

When the up/down adjustments are done correctly, the top of the door is
positioned over flush to the roof. See SPECIFICATIONS.

NOTE:

In/out door adjustment is done by loosening the hinge to door fasteners one
hinge at a time and moving the door to the correct position.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 168: Removing/Installing Rear Door Applique
Courtesy of CHRYSLER LLC

1. Use a trim stick C-4755 or equivalent, remove the door applique (1) from the rear door (2).

INSTALLATION

APPLIQUE - REAR DOOR

Fig. 169: Removing/Installing Rear Door Applique
Courtesy of CHRYSLER LLC

1. Align the door applique (1) to the rear door (2) and apply enough hand pressure in order to make sure the

clips are fully seated.

GLASS - REAR DOOR

REMOVAL



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



GLASS - REAR DOOR

Fig. 170: Removing/Installing Rear Door Trim Panel
Courtesy of CHRYSLER LLC

1. Remove the trim panel. See REMOVAL.

Fig. 171: Removing/Installing Inner Belt Molding Outboard
Courtesy of CHRYSLER LLC

2. Rotate the inner belt molding outboard while pulling up to disengage the retention tabs.
