Fig. 67: Removing/Installing Door Latch & Latch Bracket Securing Screws
Courtesy of CHRYSLER LLC

7. Remove the three screws (2) securing the door latch to the door shut face.

8. Remove the one screw (1) attaching the latch presenter to the door shut face.

Fig. 68: Electrical Connector, Carrier Plate, Screws & Door
Courtesy of CHRYSLER LLC

9. Disconnect and remove the electrical connector (1) from the door (5).

10. Remove the rear exterior handle nut attaching the door handle to the latch presenter.

11. Remove the 10 screws (4) from the carrier plate (2).

12. Remove the carrier plate (2) from the door (5).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 69: Removing/Installing Front Door Glass
Courtesy of CHRYSLER LLC

13. Remove the door glass from the module opening in the door.

INSTALLATION

GLASS - FRONT DOOR

Fig. 70: Removing/Installing Front Door Glass
Courtesy of CHRYSLER LLC

1. Install the door glass to the module opening in the door.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 71: Electrical Connector, Carrier Plate, Screws & Door
Courtesy of CHRYSLER LLC

2. Align the latch presenter to the rear exterior handle stud.

3. Align the carrier plate (2) to the door (4).

4. Install the electrical connector (1) to the door (4) and connect the electrical connector.

Fig. 72: Removing/Installing Door Latch & Latch Bracket Securing Screws
Courtesy of CHRYSLER LLC

5. Install the three screws (2) securing the door latch to the door shut face and tighten screws to 7 N.m (60

in. lbs.).

6. Install the one screw (1) attaching the latch present to the door shut face and tighten screw to 7 N.m (60

in. lbs.).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 73: Electrical Connector, Carrier Plate, Screws & Door
Courtesy of CHRYSLER LLC

7. Install the 10 screws (3) to the carrier plate (2) and tighten screws to 5.5 N.m (50 in. lbs.).

Fig. 74: Door Glass & Window Regulator Liftplate
Courtesy of CHRYSLER LLC

8. Connect the door glass (1) to the window regulator (2) by sliding the glass down into the liftplate.

9. Apply the adhesive tape to the inspection cover in the door module.

NOTE:

The glass should snap into place. Make sure the glass is secure to the
liftplate by pulling up on the glass to verify.
