4. Remove rear exterior handle nut (1).

Fig. 23: Door Glass & Window Regulator Liftplate
Courtesy of CHRYSLER LLC

5. Remove the tape covering the access hole on the carrier plate and discard. Access the window regulator

liftplate through the hole in the carrier plate.

6. Push down the door glass (1) and use a slotted screwdriver to release the tab on the window regulator

liftplate (2). Lift the glass up and secure to the header.

Fig. 24: Removing/Installing Door Latch & Latch Bracket Securing Screws

NOTE:

The window must be in proper position to disengage glass. Release tab on
liftplate must be aligned with access hole in door module. Use a slotted
screwdriver in the slot on the window regulator liftplate, press gently
outboard while pressing down on the glass to release the glass from the
liftplate.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Courtesy of CHRYSLER LLC

7. Remove the three screws (2) securing the door latch to the door shut face.

8. Remove the one screw (1) attaching the latch bracket to the door shut face.

Fig. 25: Electrical Connector, Carrier Plate, Screws & Door
Courtesy of CHRYSLER LLC

9. Disconnect and remove the electrical connector (1) from the door (4).

10. Remove the 10 screws (3) from the carrier plate (2).

11. Disconnect the outside mirror electrical connector.

12. Remove the carrier plate (2) from the door (4).

Fig. 26: Disconnecting/Connecting Inside Lock Rod
Courtesy of CHRYSLER LLC

NOTE:

The window regulator is not serviceable. The new carrier plate will come



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



13. Disconnect the inside lock rod from the latch.

Fig. 27: Inside Lock Rod, Grommet & Carrier Plate
Courtesy of CHRYSLER LLC

14. Disengage the grommet (2) and remove the inside lock rod (1) from carrier plate (3).

Fig. 28: Disconnecting/Installing Interior Handle Lock Rod
Courtesy of CHRYSLER LLC

15. Disconnect the interior handle lock rod from the latch.

equipped with the regulator assembly installed.

NOTE:

All the lock rods are color coded to help identify the location for the
particular lock rod.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 29: Grommet, Interior Handle Lock Rod & Carrier
Courtesy of CHRYSLER LLC

16. Remove interior handle lock rod (2) and grommet (1) from carrier (3).

Fig. 30: Carrier & Interior Handle
Courtesy of CHRYSLER LLC

17. Remove the interior lock rod from the interior handle.
