Fig. 60: Installing Oil Pump Gasket
Courtesy of CHRYSLER LLC

50. Install oil pump gasket (2). See Fig. 60.

1 - BELLHOUSING
2 - OIL PUMP GASKET



2007 Dodge Nitro R/T

2007 AUTOMATIC TRANSMISSION 42RLE - Service Information - Nitro



Fig. 61: Installing Oil Pump And Torque Oil Pump-To-Case Bolts
Courtesy of CHRYSLER LLC

51. Install oil pump (2) and torque oil pump-to-case bolts (1) to 30 N.m (265 in. lbs.). Do not reuse original

oil pump bolts. See Fig. 61.

1 - BOLTS
2 - OIL PUMP



2007 Dodge Nitro R/T

2007 AUTOMATIC TRANSMISSION 42RLE - Service Information - Nitro



Fig. 62: Installing Low/Reverse Accumulator
Courtesy of CHRYSLER LLC

52. Install low/reverse accumulator (1) as shown. See Fig. 62.

1 - ACCUMULATOR PISTON



2007 Dodge Nitro R/T

2007 AUTOMATIC TRANSMISSION 42RLE - Service Information - Nitro



Fig. 63: Installing Low/Reverse Accumulator Plug
Courtesy of CHRYSLER LLC

53. Install low/reverse accumulator plug (2). See Fig. 63.

1 - ADJUSTABLE PLIERS
2 - PLUG



2007 Dodge Nitro R/T

2007 AUTOMATIC TRANSMISSION 42RLE - Service Information - Nitro
