Fig. 64: Installing Low/Reverse Accumulator Snap Ring
Courtesy of CHRYSLER LLC

54. Install low/reverse accumulator snap ring (1). See Fig. 64.

1 - SNAP RING
2 - LOW/REVERSE ACCUMULATOR



2007 Dodge Nitro R/T

2007 AUTOMATIC TRANSMISSION 42RLE - Service Information - Nitro



Fig. 65: Installing Underdrive And Overdrive Accumulators And Springs
Courtesy of CHRYSLER LLC

55. Install underdrive (2) and overdrive (1) accumulators and springs. See Fig. 65.

1 - OVERDRIVE PISTON AND SPRING
2 - UNDERDRIVE PISTON AND SPRING



2007 Dodge Nitro R/T

2007 AUTOMATIC TRANSMISSION 42RLE - Service Information - Nitro



Fig. 66: Removing/Installing Valve Body
Courtesy of CHRYSLER LLC

56. Install valve body (1) into place as shown. See Fig. 66.

1 - VALVE BODY

CAUTION: Do not handle the valve body by the manual shaft. Damage could

result.



2007 Dodge Nitro R/T

2007 AUTOMATIC TRANSMISSION 42RLE - Service Information - Nitro



Fig. 67: Removing/Installing Valve Body Bolts
Courtesy of CHRYSLER LLC

57. Install seven (7) valve body-to-case bolts (1) and torque to 12 N.m (105 in. lbs.). See Fig. 67.

1 - BOLTS



2007 Dodge Nitro R/T

2007 AUTOMATIC TRANSMISSION 42RLE - Service Information - Nitro
