Fig. 13: Installing Subwoofer
Courtesy of CHRYSLER LLC

1. Connect the electrical connector and install the speaker.

2. Install the speaker mounting fasteners.

3. Install the speaker grille.

4. Connect the battery negative cable.

VIDEO SCREEN

REMOVAL

REMOVAL

Fig. 14: Removing Video Screen
Courtesy of CHRYSLER LLC

1. Disconnect and isolate the battery negative cable.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Audio/Video - Service Information - Nitro



2. Remove the video screen mounting fasteners.

3. Remove the video screen and disconnect the electrical connectors.

INSTALLATION

INSTALLATION

Fig. 15: Installing Video Screen
Courtesy of CHRYSLER LLC

1. Connect the electrical connectors and snap the video screen in position.

2. Install the video screen mounting fasteners.

3. Connect the battery negative cable.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Audio/Video - Service Information - Nitro



ASSEMBLY

AUTOMATIC TRANSMISSION - 42RLE

Fig. 18: 42RLE Bearing Orientation
Courtesy of CHRYSLER LLC

NOTE:

If the transmission assembly is being reconditioned (clutch/seal replacement)
or replaced, it is necessary to perform the TCM QUICK LEARN Procedure using
the scan tool.

1 - THRUST BEARING NO.1

5 - THRUST BEARING NO.5

2 - THRUST BEARING NO.2

6 - NEEDLE BEARING NO.6

3 - THRUST BEARING NO.3

7 - NEEDLE BEARING NO.7

4 - THRUST BEARING NO.4

-



2007 Dodge Nitro R/T

2007 AUTOMATIC TRANSMISSION 42RLE - Service Information - Nitro





2007 Dodge Nitro R/T

2007 AUTOMATIC TRANSMISSION 42RLE - Service Information - Nitro



Fig. 19: Bearing Cup Installation Special Tool - 5050A
Courtesy of CHRYSLER LLC

1. Install the output bearing cups using Installer 5050A. See Fig. 19
