Dodge Nitro. Manual - part 308

Fig. 9: Removing Subwoofer
Courtesy of CHRYSLER LLC

1. Disconnect and isolate the battery negative cable.

2. Remove the speaker grille fasteners and remove the speaker grille.

3. Remove the speaker mounting fasteners.

4. Remove the speaker and disconnect the electrical connector.

INSTALLATION

SPEAKER

FRONT DOOR

FRONT DOOR

Refer to FRONT DOOR installation procedure.

INSTRUMENT PANEL

Refer to INSTRUMENT PANEL installation procedure.

REAR DOOR

Refer to REAR DOOR installation procedure.

SUBWOOFER

Refer to SUBWOOFER installation procedure.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Audio/Video - Service Information - Nitro



Fig. 10: Installing Front Door Speaker
Courtesy of CHRYSLER LLC

1. Connect the wire harness connector and install the speaker to the door.

2. Install the speaker mounting screws. Tighten to 2 N.m (20 in. lbs.).

3. Install the front door trim panel. Refer to INSTALLATION .

4. Connect the battery negative cable.

INSTRUMENT PANEL



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Audio/Video - Service Information - Nitro



Fig. 11: Installing Instrument Panel Speaker
Courtesy of CHRYSLER LLC

1. Connect wire harness connector and install speaker.

2. Install speaker mounting screws. Tighten to 2 N.m (20 in. lbs.).

3. Install the air outlet. Refer to INSTALLATION .

4. Connect the battery negative cable.

REAR DOOR



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Audio/Video - Service Information - Nitro



Fig. 12: Installing Rear Door Speaker
Courtesy of CHRYSLER LLC

1. Connect the wire harness connector and install the speaker to the door.

2. Install the speaker mounting screws. Tighten to 2 N.m (20 in. lbs.).

3. Install the rear door trim panel. Refer to INSTALLATION .

4. Connect the battery negative cable.

SUBWOOFER



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Audio/Video - Service Information - Nitro
