7–4   FENDER, HOOD AND TRUNK LID

2. HOOD

2-1. REPAIR PROCEDURE

1. Remove the related parts.

•

Washer hose and nozzles.

•

Wiring harness and others.

2. Remove the hood.

•

Remove the hood mounting bolts from two hinge

bows.

3. Preparation of the new hood.

•

Preparation of the new hood and check damaged

areas.

Fig. 5

4. Apply the paint.

CAUTION

•

Ventilate when spraying paint. Most paint contains

substances that are harmful if inhaled or swal-
lowed.

Read the paint label before opening paint con-

tainer.

•

Avoid contact with skin. Wear an approved res-

pirator, gloves, eye protection and appropriate
clothing when painting.

•

Paint is flammable. Store in a safe place, and

keep it away from sparks, flames or cigarettes.

5. Preinstall the hood.

•

Fasten to the hood hinges bows at two places

with four bolts, carefully.

Fig. 6

FENDER, HOOD AND TRUNK LID  7–5

•

Close the hood and check the front and rear clear-

ances and level difference of hood, fender and
head lamps.

Fig. 7

6. Tighten fully.

•

After checking and adjusting the mounting posi-

tion, tighten all bolts fully.

7. Install the related parts.

•

Washer hose and nozzles.

•

Install in the reverse order in which they were re-

moved.

8. Check and adjust.

•

Check clearances and level differences.

•

Check the hood locking and unlocking condition.

•

Check spray conditions of washer liquid and ad-

just washer spray nozzles on the hood panel.

7–6   FENDER, HOOD AND TRUNK LID

3

3. TRUNK LID

3-1. REPAIR PROCEDURE

1. Remove the related parts.

•

Wiring harness and solenoid valve.

•

Lock set, latch set and others.

2. Remove the trunk lid.

•

Remove the trunk lid mounting bolts from two

hinge bows.

Fig. 8

3. Preparation of the new trunk lid.

•

Preparation of the new trunk lid and check dam-

aged areas.

4. Apply the paint.

CAUTION

•

Ventilate when spraying paint. Most paint contains

substances that are harmful if inhaled or swal-
lowed.

Read the paint label before opening paint con-

tainer.

•

Avoid contact with skin. Wear an approved res-

pirator, gloves, eye protection and appropriate
clothing when painting.

•

Paint is flammable. Store in a safe place, and

keep it away from sparks, flames or cigarettes.

5. Preinstall the trunk lid.

•

Fasten to the trunk lid hinges bows at two places

with four bolts, carefully.

•

Install bumper.

Fig. 9

BUMPER

4

2

1

(1,2)

(3,4)

FENDER, HOOD AND TRUNK LID  7–7

•

Close the trunk lid and check the clearances and

level difference of trunk lid, side panel outers and
rear combination lamps.

Fig. 10

6. Tighten fully.

•

After checking and adjusting the mounting posi-

tion, tighten all bolts fully.

7. Install the related parts.

•

Wiring harness and solenoid valve.

•

Lock set, latches and linkages.

•

Install in the reverse order in which they were re-

moved.

8. Check and adjust.

•

Clean the trunk compartment.

•

Check clearances and level differences.

•

Check the trunk lid locking and unlocking condi-

tion.

•

Check for water leaks in the trunk compartment.
