1B2-2 M161 ENGINE MECHANICAL
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
N
·
·
·
·
·
m
35 - 40
10 - 15
5 - 10
21 - 25
30
56 - 66
50 - 60
22.5 - 27.5
41.5 - 49.5
22.5 - 27.5
22.5 - 27.5
9 - 11
9 - 11
9 - 11
9 - 11
22.5 - 27.5
10
+90°
55
+90°
+90°
22.5 - 27.5
22.5 - 27.5
9 - 10
9-10
200
+90°
40
+90°
45
+90°
35
9 - 11
20
+90°
20
+90°
20 / + 90°
20 / + 90°
22.5 - 27.5
Application
Power Steering Hydraulic Lines
A/C High Pressure and Liquid Hose
Radiator Support Menber Bolt
Fuel Supply and Return Hose to Fuel Distributor
Exhaust Manifold and Pipe
Propeller Shaft to Transmission
Engine Mounting Nut
Alternator Carrier Bolt
Belt Pulley Bolt
Steering Pump Bolt
A/C Bracket Bolt
Intake Air Duct Bolt
Ignition Cable Cover Bolt
Cylinder Head Cover Bolt
Camshaft Adjuster Bolt
Cylinder Head Front Cover Bolt
Flange Bolt in Exhaust Camshaft Sprocket
Cylinder Head Bolt
Cooling Fan Bracket Bolt
Timing Gear Case Cover Bolt
M8
M6
Crankshaft Rear Cover Bolt
Vibration Damper Center Bolt
Connecting Rod Bearing Cap Bolt
Flywheel Stretch Bolt
Amarture Bolt in Flywheel
Ring and Seal Cover Nut in Flywheel
Sprocket Bolt to Exhaust Camshaft
Camshaft Adjuster Flange Bolt
Intake Flange Shaft Bolt
Exhaust Camshaft Sprocket Bolt
Camshaft Bearing Cap Bolt
