1B1-60 M162 ENGINE MECHANICAL 8. Unscrew the intake side bolts (8, 11, 13, 14) and the exhaust side bolts (1, 4, 6, 7). 9. Loosen the remaining bolts and unscrew the intake and exhaust side camshaft bearing cap bolts. Notice Number the camshaft bearing cap bolts when removing 10. Remove the intake and exhaust camshafts. Installation Procedure 1. Turn the crankshaft and position the No. 1 cylinder piston at BTDC 30°. Notice Turn the crankshaft in the direction of engine rotation. 3. Turn the camshaft using the wrench (special tool) so that the intake camshaft adjustment hole lines up with the cylinder Notice Turn the crankshaft and adjust it to OT so that no. 1 cylinder’s Install the bearing caps according to the numbers on the Tightening Torque 22.5 - 27.5 Nm 2. Install the exhaust camshaft bearing caps (2, 3, 5) and the intake camshaft bearing caps (9, 10, 12). Tighten the bolts Notice |
