DAF CF65, CF75, CF85 Series . Manual - part 943

©

 200423

5-15

Front axle and leading rear axle

TECHNICAL DATA

ΧΦ65/75/85 series

7

0

Steering rods FAD/FAC/FAX/FAL

(1) Tighten until the split pin fits (max. 60

). It is not allowed to fit a self-locking nut instead of a castle nut.

(2) Check the ball end thread for damage before fitting a new self-locking nut.

To do so, hand-tighten a non-self-locking nut on the ball joint to be checked.

If the new nut cannot be fully hand-screwed onto the entire thread, the ball end must be replaced.

Fit new self-locking nut. Apply Loctite 243 to the nut.

(3) Fit new self-locking nut.

Fitting a new self-locking nut to a

ball end with a damaged thread may

lead to dangerous situations.

A.

Steering rod attachment nut
-

if M20 castle nut

225 Nm

(1)

-

if M24 castle nut

285 Nm

(1)

-

if self-locking M20 nut

225 Nm

(2)

-

if self-locking M24 nut

285 Nm

(2)

B.

Bolt, steering rod clamping bracket
-

if  M10

47  Nm

(3)

-

if  M12

80  Nm

(3)

S7 00 718

A

B

B A

}

TECHNICAL DATA

5-16

©

 200423

Front axle and leading rear axle

0

ΧΦ65/75/85 series

7

©

 200423

6-1

Steered trailing swivel axle

TECHNICAL DATA

ΧΦ65/75/85 series

7

0

6. STEERED TRAILING SWIVEL AXLE

6.1 GENERAL

Type

Cylinder attachment arm

Wheel hub unit

Camber angle
Camber angle (X) depends on the axle load.

0% axle load when the axle is not fitted

underneath the vehicle.

100% axle load with the maximum allowable

loading capacity of the axle.

King-pin inclination

-

09G075

load capacity 7500 kg

Abutting surface of cylinder attachment arm to

swivel axle treated with

Loctite 2701

Axle journal for installing the wheel hub unit

treated with

Gleitmo 805 anti-corrosion agent

0

100

1

20’

15’ 20’

S700934

X

S700933

R

Y

King-pin inclination (Y)

8



TECHNICAL DATA

6-2

©

 200423

Steered trailing swivel axle

0

ΧΦ65/75/85 series

7

Caster

Toe
The toe is shown in a graph.

Note:

The graphs are constructed so that at 75% of the

permissible loading weight, the toe has a value of

0.5

≥ 1 mm/m toe-in. The axle load is made up of

the unladen axle weight + loading weight.

Graph explanation
1.

At the top of the graph, the axle type is

shown with axle configuration (1).

2.

With some axles, a distinction is made

between the disc brake version and the drum

brake version. To this end there is an

illustration (2) of a disc brake or a drum brake

at the top of the graph.

3.

On the left-hand side of the graph, the toe is

shown in mm/m. The values above the 0 line

show toe-in values, indicated by symbol (3).

The values under the 0 line show toe-out

values, indicated by symbol (4). The toe-out

values are indicated by negative values.

4.

At the bottom of the graph, the axle load (5)

is shown.

5.

The permitted toe at any axle load can be

read from the shaded area (6) in the graph.

6.

If the value measured lies outside the

shaded area, the toe must be adjusted to the

value indicated by the uninterrupted line (7).

S7 00 423

Z

Caster (Z)

2.5



1

2

3

4

5

6

7

8

0

-1

0,5

-0,5

-1,5

1,5

2,5

3,5

4,5

5,5

-2

2

3

4

5

6

1

mm/m

152 N

x 1000 KG

1

2

3

4

5

6

7

S700912
