DAF CF65, CF75, CF85 Series . Manual - part 276





0

3

CF65/75/85 series

Pneumatically assisted gearbox control (Servoshift)

TECHNICAL DATA

2-1

2. PNEUMATICALLY ASSISTED GEARBOX CONTROL

(SERVOSHIFT)

2.1 GENERAL

Servoshift unit
Service pressure

max. 10 bar

2.2 TIGHTENING TORQUES

The tightening torques stated in this section are
different from the standard tightening torques
included in the overview of standard tightening
torques.
Any other threaded connections that are
not specified must therefore be tightened to the
torque stated in the overview of
standard tightening torques.

When attachment bolts and nuts are to be
replaced, it is important that they are of exactly
the same length and property class as the ones
removed unless stated otherwise.

Air pipe banjo bolt (1)

38 Nm

Attachment bolts:
Servoshift unit (2)

23 Nm

V300328

2

1

ᓻ 200337

3

TECHNICAL DATA

Pneumatically assisted gearbox control (Servoshift)

CF65/75/85 series

2-2

ᓻ 200337

0

0

3

CF65/75/85 series

Pneumatic section of gearbox

TECHNICAL DATA

3-1

3. PNEUMATIC SECTION OF GEARBOX

3.1 GENERAL

If the vehicle is modified and the
configuration changed, the
electronic unit may have to be
programmed.

Note:
If the vehicle’s drive configuration is changed,
this must always be stated. The gate protection
and range-change protection frequencies
programmed into the electronic unit are related
to the drive configuration.

GV VALVE
GV valve begins to
open (C)

123

 2 mm

Total clutch pedal
travel (D)

154

 2 mm

NEUTRAL POSITION VALVE
Situation with separate air distribution block:
2 x 3/2-way valve
Service pressure

6.5 to 10 bar

Pipe connection

M14 x 1.5

Situation with integrated air distribution
block:
3/2-way valve
Service pressure

6.5 to 10 bar

Pipe connection

Not applicable

V300315

C

D

B

1

A

ᓻ 200337

3

TECHNICAL DATA

Pneumatic section of gearbox

CF65/75/85 series

3-2

GEAR LEVER SELECTOR VALVE

Range-change gear

Connection point

Colour

1

Supply

Black

3

Bleed

Red

21

Range-change gear
command (A)

White

V300488

21

1

B

A

3

PNEUMATIC SYMBOL

I

I I

V300267

1

3

21

Range

0

ᓻ 200337
