DAF CF65, CF75, CF85 Series . Manual - part 172

©

 200351

1-7

CE engine

TECHNICAL DATA

ΧΦ65/75/85 series

2

0

Vibration damper

Timing gear

Attachment bolts, cap, front of engine

(1) Tighten the attachment bolts in the order indicated

Flywheel

Flywheel housing

(1) Tighten the attachment bolts in the order indicated

Engine mounts, front

Attachment bolts

50 Nm + 90

 angular displacement

Camshaft locking plate attachment bolts

24 Nm

M8 attachment bolts for timing gear case

24 Nm

M10 attachment bolts for timing gear case

47 Nm

M12 attachment bolts for timing gear case

50 Nm

Fit timing gear case using sealant

Loctite Ultra Grey

Attachment bolts, camshaft gear

36 Nm

M201144

1

12

9

6

3

8

5

2

4

7

11

10

13

Attachment bolts,
cap, front of
engine

(1)

24 Nm

Fit cap at engine
front using sealant

Loctite Ultra Grey

Attachment bolts

30 Nm + 60

 angular displacement

M201080

20

7

11

1

14

19

17

15

13

10

18

12

16

6

4

9

3

5

8

2

M10 attachment
bolts

(1)

49 Nm

M12 attachment
bolts

(1)

85 Nm

Fit flywheel housing
using sealant

Loctite 5205

Engine bracket attachment bolts/nuts

110 Nm

TECHNICAL DATA

1-8

©

 200351

CE engine

0

ΧΦ65/75/85 series

2

Engine mounts, rear

Engine hanger brackets

Bolts attaching engine bracket to chassis

110 Nm + 90

 angular displacement

Bolts attaching engine bracket to engine

110 Nm + 60

 angular displacement

Bolts attaching support to engine bracket

170 Nm + 90

 angular displacement

Attachment bolts

113 Nm

©

 200351

2-1

CE-engine cooling system

TECHNICAL DATA

ΧΦ65/75/85 series

2

0

2. CE-ENGINE COOLING SYSTEM

2.1 GENERAL

Thermostat

Header tank pressure cap

Pressure-testing the cooling system

Thermostat opening temperatures:
Thermostat opens at

approx. 81

C

Thermostat fully open at

approx. 94

C

Full thermostat opening

14.3 mm

Pressure relief valve opening pressure

1 - 1.2 bar

Underpressure valve opening pressure

0.1 - 0.02 bar

Closed pressure cap position

Brand name (2) legible horizontally or 60

 before

this position.

1

2

M201272

Closed pressure cap
position

Brand name (2)
legible horizontally or
60

 before this

position.

Test pressure

0.5 - 0.7 bar

TECHNICAL DATA

2-2

©

 200351

CE-engine cooling system

0

ΧΦ65/75/85 series

2

2.2 TIGHTENING TORQUES

The tightening torques specified in this section
are different from the standard tightening torques
cited in the overview of the standard tightening
torques. The other threaded connections not
specified must therefore be tightened to the
torque cited in the overview of standard
tightening torques.

When attachment bolts and nuts are replaced, it
is important that - unless stated otherwise - these
bolts and nuts are of exactly the same length and
property class as those removed.

Coolant pump

Thermostat housing

Radiator

Attachment bolts

24 Nm

Attachment bolts

10 Nm

Attachment nuts

60 Nm
