DAF CF65, CF75, CF85 Series . Manual - part 1237

©

 200419

91

GEARBOX



3

3

0694798

Lifting eye for demounting/mounting main shaft

0694814

Gripper for demounting intermediate shaft tapered roller

bearing (i.c.w. 0535662)

0694815

Gripper for demounting intermediate shaft tapered roller

bearing

0694816

Installer for oil seal (60 x 74), output shaft

0694798

1x56 137 200

0694814

0694815

0694816

GEARBOX

92

©

 200419

3

3

0694817

Protective sleeve for mounting oil seal and selector
shaft scraper ring

0694818

Driving tool for removing and fitting selector housing
bearing

0694819

Lifting plate, auxiliary and main shafts

0694858

Adapter, oil pump drive cam puller (i.c.w. 0535662)

0694817

0694818

0694819

0694858

©

 200419

93

GEARBOX



3

3

0694903

Output shaft lock plate driving tool

0694990

Threaded spindle for fitting Voith retarder on gearbox

output shaft (i.c.w. 0694992)

0694991

Voith retarder valve threaded spindle nut

0694992

Thrust bearing for fitting Voith retarder to gearbox (i.c.w.

0694990)

0694903

0694990

0694991

0694992

GEARBOX

94

©

 200419

3

3

0694993

Voith retarder demounting/mounting plate

0694994

Retarder centring plate

0694995

Retarder centring plate

0694996

Retarder positioning tool

0694993

0694994

0694995

0694996
