DAF CF65, CF75, CF85 Series . Manual - part 1238

©

 200419

95

GEARBOX



3

3

0694997

Retarder positioning tool

1240037

Output shaft seal driving tool

1240038

Gearbox front cover seal driving tool

1240039

Adapter for gearbox front cover oil seal (i.c.w. 1240038)

0694997

1240037

1240038

1240039

GEARBOX

96

©

 200419

3

3

1240040

Selector shaft seal driving tool

1240082

Prop shaft socket wrench, M40

1240083

Prop shaft socket wrench, M55 (FAD only)

1240099

Input shaft oil seal guide sleeve

1240040

1240082

1240083

1240099

©

 200419

97

GEARBOX



3

3

1240100

Input shaft seal driving tool

1240116

Quick-release coupling for bleeding HGS gearbox

1240410

Shim for mounting/demounting selector shaft and

auxiliary shaft (i.c.w. 0694779)

1240412

Bolt (i.c.w. 1240470)

1240100

V300891

1240410

1240412

GEARBOX

98

©

 200419

3

3

1240413

Centring sleeve for mounting/demounting selector shaft
and auxiliary shaft (i.c.w. 0694779)

1240414

Holder for mounting/demounting selector shaft and
auxiliary shaft (i.c.w. 0694779)

1240424

Assembly valve cylinder adjusting and pressure-testing
tool

1240425

Interlock lock bolt

1240413

1240414

1240424

1240425
