DAF CF65, CF75, CF85 Series . Manual - part 1235





©

 200419

83

GEARBOX



3

3

0192540

Demounting/mounting jig for main shaft/secondary shaft

0192541

Synchronisation body puller for demounting main shaft

0192542

Puller for main shaft tapered roller bearing

0192544

Driving tool for mounting ball joint cover in gearbox

housing

0192540

0192541

0192542

0192544

GEARBOX

84

©

 200419

3

3

0192545

Driving tool for fitting bearing bush in selector housing

0192546

Selector shaft guide sleeve

0192547

Secondary shaft guide sleeve, 3rd/4th gear

0192548

Adapter for M65x2 (i.c.w. 0535662)

0192545

0192546

0192547

0192548

©

 200419

85

GEARBOX



3

3

0484966

Centring pin for clutch plate/clutch release assembly

0484978

Puller, output shaft flange

0485063

Oil seal punch, gearbox output shaft

0485099

Puller, output shaft forked coupling

0484966

0484978

V300890

0485099

GEARBOX

86

©

 200419

3

3

0535409

Input shaft seal driving tool

0535410

Odometer connecting piece seal driving tool

0535423

Gearbox front cover seal driving tool

0535659

Selector shaft seal and dust seal driving tool

0535409

0535410

0535423

0535659
