DAF CF65, CF75, CF85 Series . Manual - part 1201

©

 200423

3-43

Inspection and adjustment

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ85 series

5

3.49 CHECKING THE AIR SUSPENSION BELLOWS

1.

Raise the chassis to driving height using the
remote control.

2.

Clean the air bellows using a cleaning cloth
or a soap solution, if required.

3.

Check the air bellows for cracks and
damage. If there are any cracks or damage
through which the webbing is visible, the air
bellows should be replaced.

4.

Check the air bellows, bellows seating and
air line connections for leaks.
Check that the air bellows are not chafing
against air lines, etc. when in the driving
position.

3.50 CHECKING THE OPERATION OF THE AUTOMATIC LUBRICATION SYSTEM

1.

Check the system for line fractures and
operation of the jets.

2.

Check whether all lubricating points are
lubricated.

3.

Check the lubricant level in the reservoir. If
necessary, top up the reservoir, see chapter
"Draining and filling".

M9040

C900331

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

3-44

©

 200423

Inspection and adjustment

5

ΧΦ85 series

©

 200423

4-1

Removal and installation

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ85 series

5

4. REMOVAL AND INSTALLATION

4.1 REMOVAL AND INSTALLATION, INTERIOR FILTER ELEMENT

Removing interior filter
1.

Open the grille.

2.

Push the locknut on the filter casing to one
side and remove the filter element.

Fitting interior filter
1.

Fit the filter element.

2.

Push the filter element into the locknut on the
filter casing.

3.

Close the grille.

Engine, cooling system and fuel system

K1 01 033

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

4-2

©

 200423

Removal and installation

5

ΧΦ85 series

4.2 REMOVAL AND INSTALLATION, AIR FILTER ELEMENT

Removing the air filter element
1.

Loosen all the clamping brackets (1) of the
air filter cover (2).

2.

Remove the air filter cover (2).

3.

Remove the air filter element (3).

4.

Clean the inside of the air filter housing and
the air filter cover.

5.

When replacing the air filter element, reset
the air filter indicator, if fitted, by pressing the
button on the indicator.

i400443

1

5

2

4

3

i400869
